Biometrics turnstyle gates , turnstile tripod With Fingerprint
Access Control System
Specifications:
| Technical Parameters |
| Size | 1200 mm (L) * 280 mm (W) * 1000 mm (H) |
| Working voltage | AC220±10%V 50±10%HZ |
| Arm width: | 510 mm |
| Support force of arm: | 60 kg |
| Passage width: | ≤600 mm |
| Time of opening: | 0.2 second |
| Pass speed: | 30 persons/min |
| Emergence: | When power off, arm open automatically |
| Normal running life: | 3 million |
| LED light: | direction arrow |
| Direction: | single or bi-directional (optional) |
| Working environment: | indoor/outdoor (with a tent over) -10℃～70℃ |
| Relative humidity: | ≤90% coagulation free |
| Communication interface: | standard RS 485 interface, distance ≤1200m |
| Housing material | domestic standard 304# stainless steel |
| Working movement | DC 24V solenoid valve |
| Input interface: | +12V level signal or pulse width>100 ms 12V pulse, drive current>10 mA |
Feature & function:
1. Auto replacement function, reposition after person pass by
2. Anti tail function auto-lock once turn 120° .
3. Arms auto drop when power off , insure unblocked when accident
4. Standard electronic interface, remote control through internet
which is also could connect variety card readers and receive relay
signal to work
5. Diverse control mode optional, changeable due to varying,
convenient for your manage
6. Auto alert error function, comfort for user maintain and operate
7. Manual button or remote control ,Bio-directional passage
8. Open signal with memory or with out set function
9. Red and green light to show pass or stop, leisure to exit and
entrance
Application:
1. Entertainment Places: Movie theaters, Fitness halls, Country
clubs, Fairground, Clubs,Swimming Hall,
Fitness Gym.
2. Public Places: Subway, Airports, Stations,Library, Bookstores,
Parks, Exhibition halls, Stadium,
Museums,Apartments,Residence Area, Offices,Commercial buildings.
3. Business Organizations:
Hotel,Factory,Bank,Prison,Hospital,School, Enterprise’s Entrance
and Exit
Attendance.
