304 stainless steel Retractable wing flap Pedestrian Barrier Gate / entrance door

    Buy cheap 304 stainless steel Retractable wing flap Pedestrian Barrier Gate / entrance door from wholesalers

    Buy cheap 304 stainless steel Retractable wing flap Pedestrian Barrier Gate / entrance door from wholesalers
    • Buy cheap 304 stainless steel Retractable wing flap Pedestrian Barrier Gate / entrance door from wholesalers
    • Buy cheap 304 stainless steel Retractable wing flap Pedestrian Barrier Gate / entrance door from wholesalers

    304 stainless steel Retractable wing flap Pedestrian Barrier Gate / entrance door

    Ask Lasest Price
    Brand Name : Goldantell
    Model Number : GAT-204
    Certification : CE/ROHS/FCC/IS9001
    Price : negotiation
    Payment Terms : T/T ,western Union,LC,Paypal, L/C
    Supply Ability : 2,000pcs per month
    Delivery Time : 7 working days after received your payment
    • Product Details
    • Company Profile

    304 stainless steel Retractable wing flap Pedestrian Barrier Gate / entrance door

    304 stainless steel Retractable wing flap Pedestrian Barrier Gate / entrance door


    Flap Barrier Gate Specifications:


    Item


    GAT-204-1( single motor )
    GAT-204-2( double motors )


    Working voltage:


    AC220±10%V 50±10%HZ


    Retractable arm length:


    265mm


    Time of opening:


    0.6 second


    Passage width:


    ≤600mm


    Pass speed:


    40 persons/min (open), 25-30 persons/min (closed)


    Reset time after break down:


    10 seconds


    Direction:


    single or bi-directional (optional)


    Transit speed


    30-40 people/minute


    Input interface:


    +12V level signal or pulse width>100 ms
    12V pulse, drive current>10 mA


    Communication interface


    RS485/232


    Features of Flap Barrier Turnstile:

    1. working method can be set by the buttons on the main panel
    2. This model is double wing flap gate, low noise, smaller casing, save space
    3. Anti-pinch by mechanism and sensor If there is block during return of gate, motor stops working automatically. Reset again after a default delay, the force 2Kg.
    4. Anti-illegal in, anti-intrusion, auto close for reverse direction.
    5. Anti-collision, gate closes when no valid signal is given.
    6. Gates can be synchronous
    7. uto-reset. If not go through in a preset time, pass right would be cancelled automatically. (1-60s adjustable), default time is 10s.
    8. Reset function by photocells,Anti-pinch function by photocells, ( 3 or 5 pairs sensors)
    9. Compatible with Access control system, consumption system, ESD system, E-ticket system and so on.


    introdution of flap barrier gate:


    Goldantell smart flap turnstile (flap automatic gate) is s a high-tech product which mainly provides intelligent management to passageway. It is a upgrade product of intelligent tripod turnstile and swing barrier. this product is finely processed with complete functions and high level, suitable for high-level neighborhoods, intelligent buildings, hotel, subway, port and club,etc.

    This equipment is subtly integrated with machine, electronics, micro-processor control and ID identification, provides convenience for the use of card reader identification equipments, such as IC card, ID card, bar code and fingerprint. It can carry out intelligent control and management to the passageway through choosing various identification equipments and adopting fair, reliable security protection, alarming equipment and direction indicating equipments...



    application:




    Control system:
