    Coin access and Barcode Flap barrier gate of visitor ticketing management system

    Ask Lasest Price
    Brand Name : Goldantell
    Model Number : GAT-229
    Certification : CE/ROHS/FCC/SGS/IS9001
    Price : negotiation
    Payment Terms : T/T ,western Union,LC,Paypal, L/C
    Supply Ability : 2,000pcs per month
    Delivery Time : 7 working days after received your payment
    • Product Details
    • Company Profile

    Coin access and Barcode Flap barrier gate of visitor ticketing management system



    Coin access and Barcode Flap barrier gate of visitor ticketing management system


    Flap Barrier Gate Specifications:



    Item


    GAT-229-1( single motor )
    GAT-229-2( double motors )


    Working voltage:


    AC220±10%V 50±10%HZ


    Time of opening:


    0.6 second


    Passage width:


    ≤600mm


    Pass speed:


    40 persons/min (open), 25-30 persons/min (closed)


    Reset time after break down:


    10 seconds


    Direction:


    single or bi-directional (optional)


    Input interface:


    RFID Reader&Fingerprint Reader ,Coin acess,QR code reader,
    Bar code System,ESD Tester Access Control, remote button


    Communication interface


    RS485/232


    Support


    operating video& Instruction will be sent to clients to help them better use the machines


    Type


    Retractable Flap Turnstile


    Description:



    1. Anti-illegal in, anti-intrusion, auto close for reverse direction.
    2. Anti-collision, gate closes when no valid signal is given.
    3. Gates can be synchronous
    4. uto-reset. If not go through in a preset time, pass right would be cancelled automatically. (1-60s adjustable), default time is 10s.
    5. Reset function by photocells,Anti-pinch function by photocells, ( 3 or 5 pairs sensors)
    6. Compatible with Access control system, consumption system, ESD system, E-ticket system and so on.
    7. One way or two way control
    8. Unit can be controlled and administered by remote control

    9. working method can be set by the buttons on the main panel
    10. This model is double wing flap gate, low noise, smaller casing, save space
    11. Anti-pinch by mechanism and sensor If there is block during return of gate, motor stops working automatically. Reset again after a default delay, the force 2Kg.
    System Integration:

    Integrate with access control system required by customers, and built-in reader appointed by customer.

    Integrate with visitor management system.

    Integrate with ticketing system.


    Direction Indicator:

    The installation position of direction indicator can be adjusted.

    The pattern of direction indicator can be customized


    control system:

    access control system


    access control system: fingerprint/ face recognition/
    card reader/ QR code/ barcode ticket system.


    charge management system

    counter, coin- operation.


    support special function

    ESD tester system and function



    application:

    Entertainment PlacesMovie theaters, Fitness halls, Country clubs, Fairground, Clubs,
    Swimming Hall,Fitness Gym
    Public PlacesSubway, Airports, Stations,Library, Bookstores, Parks, Exhibition halls, Stadiums, Museums,Apartments,Residence Area, Offices,
    Commercial buildings.
    Business Organizations

    Hotel,Factory,Bank,Prison,Hospital,School, Enterprise’s Entrance and Exit Attendance
