Office Entrance Stainless Steel Drop Arm Turnstile With 600mm
Passage Width
Application:
Subway Station, Bus Station,Airports, Hoverport, Terminal,Tourism
Sports,Exhibition,
Hotel,Factory,Bank,Prison,Hospital,School,Library,Theater,Canteen,Swimming
Hall,Fitness Gym, Residence Area,
Enterprise’s Entrance and Exit Attendance,Gateway Guard,Toll
Management,Special Access Control.
Functions & features:
1. Alarm function: when arms are pushed by force illegally, alarm
will be triggered automatically and arms will be set locked.
Self-examine
2. Function: it is good for customer to maintain and use.
3. Turnstile can set the working condition by press the button of
main control board.
4. Anti- pinch function: turnstile have Mechanical / infrared
induction Anti- pinch functions (when it is meet the hinder during
the reset time, the electrical machine closed work automatically in
specified time, the
turnstile will default the delayed and reset again till reset
succeed), small intensity (≤2Kg).
5. The turnstile will close the door when somebody enter the gate
illegal, Tailgating or break into negative direction gate.
6. Before received the open signal, the turnstile will lock
automatically.
7. The retractable can be adjustable (specific to double swing
gate).
8. Automatic Reset Functions: after you swap the card, during the
specific time (the system is 10s), if you
didn’t pass the turnstile, the system will cancel your authority
automatically to pass the gate, (reset time
is 1~60s you can adjust it what time is suit for you). Totally meet
the fire protection needs.
9. Infrared sensor reset, infrared induction anti-pinch function (3
or 5 infrared optional).
10. The turnstile can work with door access control system/
consumption system /biometric recognition
system/ ESD system and so on.
11. The turnstile direction: single or bidirectional optional
(pedestrian can enter and exit from one pair of
turnstile). Can manager and long-range control the turnstile
directly by managing the computer.
Product details show:
1. Appearance: customized according to customer’s requirement.
2. Stainless steel thickness of the cabinet: customized within
1.2~2.0mm.
3. Material of the cabinet: 304 / 316 grade stainless steel.
4. Surface finish of the cabinet: satin finish / polishing / anti-
fingerprint/frosted finish / electroplating /
baking finish.
Specifications:
| Technical Parameters |
| Housing material: | domestic standard 304# stainless steel |
| Size: | 1200mm (L) * 165mm (W) * 1000mm (H) |
| Working voltage: | AC220±10%V 50±10%HZ |
| Working movement: | DC24V solenoid valve |
Arm length (optional): | 250-500 mm |
| Support force of arm: | 60kg |
| Passage width: | ≤600 mm |
| Time of opening: | 1second |
| Pass speed: | 40 persons/min (open), 25-30 persons/min (closed) |
| Emergence: | When power off, arm open automatically |
| Normal running life: | 3 million |
| LED light: | direction arrow |
| Direction: | single or bi-directional (optional) |
| Working environment: | indoor/outdoor (with a tent over) -10℃～70℃ |
| Relative humidity: | ≤90% coagulation free |
| Communication interface: | standard RS485 interface,distance ≤1200m |
| Input interface: | +12V level signal or pulse width>100ms 12V pulse,drive current>10mA |
Competitive Advantage:
1. More than 10 years powerful ODM/OEM ability,could make product
shape design,custom logo,custom
package.
2. We can provide not only product, but also system software
management.Save your time and cost.
3. Special service from Goldantell:
For repairing,no need you return back product,only need you take a
video,our engineer will instruct you,if
spare parts was damaged in 1 year,we will send you spare parts by
fastest express,you no need bear
any fee.
4. Friendly and professional customer service people help you in 16
hours.
