Fast Speed Security Flap Turnstile Gate With Face Recognition &
RFID safety Access Control
Description of Security Flap Turnstile Gate:
Goldantell security flap turnstile gate is a high- tech product
which mainly provides intelligent management to
passageway. It is a upgrade product of intelligent tripod turnstile
and swing barrier. this product is finely
processed with complete functions and high level, suitable for
high- level neighborhoods, intelligent
buildings, hotel, subway, port and club,etc.
Security Flap Turnstile Gate Specifications:
| Item | GAT-221-1( single motor )
GAT-221-2( double motors ) |
| Name | Boat type flap turnstile gate |
| Technical parameters |
| Size: | 1200/1400mm (L) * 300mm (W) * 980mm (H) |
Retractable arm length: | 260 mm |
| Pass speed: | 40 persons/min (open), 25-30 persons/min (closed) |
| Passage width: | 550mm |
| Normal running life: | 3 million |
| Time of opening/closing: | 0.6 second |
Time to work after power on: | 3 seconds |
Reset time after break down: | 10 seconds |
| Direction: | single or bi-directional (optional) |
| Drive motor: | DC 24 V brush motor |
| Working environment: | indoor/outdoor (with a tent over) -10℃～70℃ |
Communication interface: | standard RS 485 interface, distance ≤1200m |
| Input interface: | +12V level signal or pulse width>100 ms
12V pulse, drive current>10 mA |
| Relative humidity: | ≤90% coagulation free |
| Housing material: | domestic standard 304 # stainless steel |
| Working voltage: | AC220±10%V 50±10%HZ |
Security Flap Turnstile Gate Size:
Security Flap Turnstile Gate Application:
Entertainment Places | Movie theaters, Fitness halls, Country clubs, Fairground, Clubs,
Swimming Hall,Fitness Gym |
| Public Places | Subway, Airports, Stations,Library, Bookstores, Parks, Exhibition
halls, Stadiums, Museums,Apartments,Residence Area, Offices,
Commercial buildings. |
Business Organizations | Hotel,Factory,Bank,Prison,Hospital,School, Enterprise’s Entrance
and Exit Attendance |
Access control system:
1. we can offer the access control system: fingerprint/ face
recognition/ card reader/ QR code/ barcode ticket system.
2. support special function: counter, coin/token operation.
3. ESD tester system Human body wristband and foot test
Package of Security Flap Turnstile Gate:
