Factory Entrance Fingerprint Scan Anti-static ESD Wrap Strap check
system swing barrier gate with software
Quick Description
◊ It can carry out intelligent control and management to the
passageway through choosing various identification equipment and
adopting fair, reliable security protection, alarming equipment and
direction indicating equipment.
◊ Pass direction: one way or two ways to set for you.
◊ It has a visible high glass panel that prevents a user from
climbing over the gate to gain unauthorized access. Glass panel
slides open horizontally to provide an unobstructed passageway.
◊ Higher flow rate and better anti-tailgate functions.
Specifications List
| Technical parameters of turnstile gate |
| Size of housing: | 1400mm (L) * 200mm (W) * 1000mm (H) |
| Pass through width | widely 60 /90cm ,or (120cm and custom-made) for a pair |
| Pass speed: | 40 persons/min (open), 25-30 persons/min (closed) |
| Drive motor: | standard DC 24 V brush motor ( or brushless motor) |
| Normal running life: | 3 million |
| Time of opening/closing: | 0.6 second |
| Time to work after power on: | 3 seconds |
| Reset time after break down: | 10 seconds |
| Direction: | single or bi-directional (optional) |
| Working environment: | indoor/outdoor (with a tent over) -10℃～70℃ |
| Communication interface: | standard RS 485 interface, distance ≤1200m |
| Input interface: | +12V level signal or pulse width>100 ms
12V pulse, drive current>10 mA |
| Relative humidity: | ≤90% coagulation free |
| Housing material: | domestic standard 304 # stainless steel |
| Working voltage: | AC100-240V, 50±10%HZ |
ESD Detection Device Descriptions
1. Item model: GAT-ESD303
2. It can stand and work alone, or be built into different styles
of Channel turnstile gates like a Flap barrier or tripod.
3. Has has a 4.3-inch LCD screen, voice prompts, intuitively
display the test results, no software.
4. Parameters of ESD Checker_ Factory default Settings (stand-alone
version)
Wrist band: 750KΩ – 10MΩ, test range: 750KΩ – 10MΩ, accuracy ±10%.
Anti-static shoes: 750KΩ – 100MΩ, test range: 750KΩ – 100MΩ,
accuracy ±10%.
5. Sure!! You can choose to add a variety of access control systems
such as card swiping function, networking function. This product
can work with electric door or intelligent turnstile gates in the
air shower (please note this customized function will increase the
price and cost).
Functions & Features
1.With function of self-examine and alarm, it is convenient for
maintain and use
2. being able to program operation state by the small keyboard in
the main board.
3. Swing arm stops moving when it is blocked, which prevents
pedestrians from being nipped and from hurt
4. Arms are automatically locked until an opening signal is
received
5. Arms synchronization (adjustable)
6. Light and sound alarm is generated when the illegal invasion and
the tail followed.
7. Automatically reset function: It will automatically lock if the
pedestrian hasn’t pass through the channel in the pre-set time
after the opening.
8. The passing time is adjustable.
Project Application
a. Movie theaters, fitness halls, Country clubs, Fairground, Clubs,
Swimming Hall, Gym.
b. Hotel, Factory, Bank, Prison, Hospital, School, Enterprise’s
Entrance and Exit Attendance
