TCP / IP communication Half height Entry Coin operated turnstile,
Coin machine door
Product Profile
1. Standard features: Made of 304 /316 stainless steel, Goldantell
tripod turnstile with nice and elegant shape, anti-rust,durable,
Resistant to external damage.
2. Standard Functions: Rectangular box and brake lever to be a
passage,provide orderly passage to people. Prevent illegal in and
out.Arms off in emergency case.
3. Application place: This item is widely used in
station,pier,subway,factory,office building,intelligent community,
hotel, clubs, enterprise, etc.
4. Classification: 1) full automatic 2) semi-automatic 3) manual,
the semi-automatic is the most widely used.
Technical Parameters of Coin / token machine Features of Coin /
token machine
Technical Parameters Of Token Machine | Features Of Token Machine |
Coin Diameter 18mm~30mm
Coin thickness 1.5mm~2.6mm
This set system including:coin controller+stainless steel collector
box;
Operating voltage DC12V±10%;
Pulse width 20ms/40ms/100ms
Operating current 650mA;
Output mode OC.
Operating Temperature -15℃ ~+ 75℃
Package size 455mm*340mm*272mm | 1.Suitable for a variety of coins.
2.CPU process control, and accurate scoring.
3.Special precision / normal stall, coin smoother.
4.Pulse output,available widths.
5. Prevent phishing and other means of cheating,cheat alarm.
6.To prevent money being diverted to(400400M) the small.
7.Wire part of the whole SMT technology, quality and stability. |
Turnstile Features & functions
-Low noise, no mechanical impact
-Single directional or Bi-directional
-High operation with quick response
-Excellent design, with high quality
-Robust, rigid , anti-rust and durable
-Smoothly working system
-Self-test function
Added function
-Counting function available (counter)
-Information display option (LCD display screen)
-Audible sound prompt
-Invalid entering alarm
-Auto-lift-arm function (full automatically type)
Specification
Product Model | GAT-301 |
Product Size | 1200 *280*1000mm |
Path width | in 600 |
Direction | single or bi-directional (optional) |
Time of opening/closing | 0.6 second |
Pass speed | 30 persons/min (open), 25-30 persons/min (closed) |
| Reset time after break down | 10 seconds |
| Normal running life | 3 million |
| Working environment | indoor/outdoor (with a tent over) -10℃~70℃ |
| Drive motor | DC24V brush motor
|
Our Project Introduction For Your Reference
1. as for entry (input) access, drop a coin / TOKEN into Slot on gate machine side, gate will soon open for users.
2. as for exit (output) access, free access with Infrared
sensor.When sensing people enter into infrared area, gate will
automatically open to let people freely out.
Packing details:
a. Inner package - bubble bags
b. Outer package -a whole crate package is advised; or wooden case
package.
Shipment terms
a. if <10pc, ship in 7 working days
b. > 50, ship in 10-15 working days
c. For customized product, with ship in 7-12 working days according
to the detailed customized requirements
