Face Scan Tripod Turnstile Gate

Ask Lasest Price
Brand Name :	Goldantell
Model Number :	GAT-305
Certification :	CE/ROHS/FCC/IS9001
Price :	negotiation
Payment Terms :	T/T ,western Union,LC,Paypal
Supply Ability :	1,000pcs per month
Delivery Time :	7 working days after received your payment

Add to Cart

Product Details
Company Profile

Face Scan Tripod Turnstile Gate

Access turnstyle waterproof high quality intelligent face scan turnstile face scan turnstile cheap price sale

Features & Functions

Features of thermal scanner face recognition terminal

1. Support 1: N verification ,1: N mode binocular live detection to prevent photo and video attacks;
2. In the case of external ID card reading, support 1:1 verification ,1:1 verification under the identification pass rate
99.99%;
3. 1:N pattern recognition accuracy is high, face database is 5000,1/10000 false recognition rate ,99.87% pass rate;
4. Face tracking and detection takes about 20 ms, and in vivo detection takes about 200 ms,.
5. The facial feature extraction time is about 150 ms, and the total face ratio time is about 400 ms.
6. Using the video stream based dynamic face detection, tracking recognition algorithm,
7. Support for offline storage of 100,000 face photos and recognition records;

Product Description

Technical parameters of Face recognition terminal
Size	155mm105mm660mm (length * width * height)	Appearance Material	Aluminum alloy case, tempered glass panel
Wiegand / RS23	Wiegand format 26/34, RS232	Identification distance	0.3-0.5 m
Camera	automatic light burst	Screen	8 inches LCD screen
Power	DC12V/2A	Identification Speed	Face Detection And Tracking 20 Ms
Weight	0.9 KG	temperature detection	2~3 seconds per person
Technical parameters of turnstile gate
Size of housing	1200 L * 280 W * 1000 H (mm)	Pass width	600mm
Direction	single or bi-directional (optional)	Pass speed	35 persons/min (open), 25-30 persons/min (closed)

◊ The system supports switching in 1:1 and 1:1 N mode and operates
based on Android 7.1 and above system environments.
◊ It has the characteristics of fast face recognition, high
accuracy, high security and good stability.
◊ This product is a special type of face temperature rapid detection
products, can replace the traditional market thermometer.
◊ Equipping with intelligent Tripod turnstile, flap turnstile and
swing barrier.It is finely processed with complete functions and
high security level, suitable for high-level neighborhoods,
commercial building,and so on.

Product Usage

1. For Desktop.....The nut needs to be removed, the tail wire is passed through the stainless steel bracket and the nut in sequence, and the angle is tightly tightened; it is suitable for program debugging.

2. For Turnstile Gate....We can attach it on the top of turnstile gate, or fix in extra pillar as another option reference.

3. For wall-mounted.....Firstly, put the white 86 switch back box on the wall at 1400mm,and the specific height should depend on the actual use.And then mark the four corners of the back box with a pen, drill four holes with an impact drill, place the rubber plug in the hole, fix the back box with screws, and then do the cable.
