Heavy Duty Reserved DC 6v electric Automatic remote control parking
space saver with logo
Battery usage
1. When the battery is fully charged, the expected use is 300
operations or approximately 3 months assuming 2 lifts and 2 downs
per day.
2. When the battery is low and dry, an audible alarm will sound to
remind the owner to charge the battery. Open the control box with
the key and take out of the battery, take home to re-charge. This
must be plugged into 220/240 volt power. After 12 hours’
recharging, it’ll be ok.
3. In case of an emergency and the unit is standing up and will not
operate, use the hex key (supplied, it’s a good idea to leave this
key and key of the main box in your car), to open the main box and
to undo the screw. The pin will then be released. Remove the pin
and lay the whole unit down.
Standard Specification
| Item | GAT-ABS10 |
| Power Voltage (V) | DC 6~7V |
| Dimension (mm) | 450x450x65mm |
| Static Power (W) | 12m |
| Working Power (Storage Battery) | 6V 7 AH |
| Working Current (A) | 1.5 A |
| Remote Controlled Distance | ≤30m |
| Environment Temperature | -30~+65 |
| Up or Down Time | 5-6 seconds |
| N.W (kg) | 11 |
| Work Time/Recharge | 3-4 Months |
| G.W (kg) | 12.5 |
| UP Height (mm) | 390 |
| Down Height (mm) | 60 |
Security Functions
1. Heavy Duty and Durable: The housing adopts high quality steel
rolling which can bear Max. 5 ton weight. With spray plastic
coating, which is waterproof, rustproof and dust proof enough to
last about 5 years in hard weather. The sway arm made of steel
rolling won`t deform even it is crushed by a vehicle.
2. Anti- disconnecting for Power Safety: The power connection is
anti- disconnecting design in case the use misplace the battery
causing short circuit.
3. Auto- repositioning: the external force could not change the
sway arm position when it is vertical; when the sway arm is forced
to a horizontal position, it will reposition vertically, unless the
user uses remote control to put it horizontally.
4. Noise- free: The transmission design on motor makes almost zero
noise, which is good for battery and motor longevity and less
friction, also goods for quiet environment.
5. Manual control in case of no power: In case the power is off,
just manually control the parking lock in emergency.
6. Alarm Against a Low Battery: If the battery is low, the parking
lock will alarm to remind the owner to recharge the battery.
Details Photos
Custom Display
- 3. Equip multiple quantity of remote controls for one unit lock,
max. 20pcs. ( regularly, 2pcs per unit)
