High-Security Optical Face scanner hotel turnstile RFID
bi-directional pass barrier system
Brief Description
1. Both RFID card reader,face recognition and QR code scanner could
be integrated for better user experiences.
2. Higher flow rate and better anti-tailgate functions.
3. Indicator and LED light can achieve real time displaying which
improve the passing rate and convenient maintain.
4. Auto-reset. If not go through in a preset time, pass right would
be cancelled automatically. (1-60s adjustable), default time is
10s.
5. Multi alarm modes: illegal intrusion, anti-intrusion, anti-follow,
overtime alarm etc.
6. Bi-directional or single way optional.
7. Gate auto-open when power is off to meet the fire protection
requirements.
Technical specification
| 1 | Cabinet dimension | 1400 (L) x 120 (W) x 1000 (H) mm |
| 2 | Cabinet material | 304 stainless steel (316 ss can be custom-made) |
| 3 | Switching power supply | AC220±10%V 50Hz or AC110±10%V 60Hz |
| 4 | opening/closing time | 0.2s |
| 5 | Arm material | thickness 10mm Acrylic, or tempered glass or steel (custom) |
| 6 | Access mode | single in/out or Bidirectional |
| 7 | Passthrough Width | 900mm (or custom) |
| 8 | Mechanism | DC Brushed motor+Clutch (or Servo motor) |
| 9 | Communication interface | RS485, TCP/IP |
| 10 | Infrared sensor | 6~10 pairs |
| 11 | Optimal flow rate | 40 persons/min (open), 35 persons/min (closed) |
| 12 | Reset time after break down | default 10s can be changed to fit different demands |
| 13 | MCBF | 5,000,000 Cycles |
| 14 | Working humidity | 30%~95% |
Security Features
◊ Anti-Tail gaiting feature built in to prevent unauthorized entry.
◊ The wings will open automatically during power interruption, and
recover N/C mode after poweron(optional)
◊ Fast opening and closing time.
◊ Built-in mechanical lock to prevent forced opening of swing flaps.
◊ Fail-safe design ensures that the swing flaps retract back into
the housing to allow unblocked access in the event of a power
failure.
◊ Active infra-red beams are located in the housing passage to
detect personnel or objects crossing the flap barrier to prevent
the flaps from causing injury or damage.
◊ Long service life with low operational cost.
Operation Application
Bank
Fitness Gym
Factory
Hotel
Movie theaters
Office buildings
Packing Details
1. Exported product: Wooden case package of Export exempted from
inspection plus pearl wool and plastic wrap
2. Domestic: Bubble wrap plus carton or pearl wool plus wooden
packaging.
3. To better ensure the safety of your goods, professional,
environmentally friendly, convenient and efficient packaging
services will be provided.
FAQ
1. How long is your warranty period?
Vivian: One-year guarantee & Lifetime technology support.
2. How about the payment method?
Vivian: If order amount <=5000USD, 100%T/T in advance. If order
amount >5000USD, it is 50%T/T in advance and 50%T/T before
shipment (can be further negotiated for best cooperation between
us).
3. Which payment terms are you accept?
Vivian: T/T, Western Union, LC, PayPal, etc.
4. Can we visit your factory?
Vivian: Yes. Any time will be welcome.
5. What is your MOQ?
Vivian: Any quantity is acceptable.
